Pitless Weighbridge
click on image for big preview
Technical Specification:
| Capacity | Division (Accuracy) | Plateform Size (Pan Size) |
|---|---|---|
| 50000 Kg | 5 Kg | 6.5 x 3 mtr |
| 50000 Kg | 10 Kg | 7.5 x 3 mtr |
| 60000 Kg | 10 Kg | 6.5 x 3 mtr |
| 60000 Kg | 10 Kg | 7.5 x 3 mtr |
| 80000 Kg | 10 Kg | 6.5 x 3 mtr |
| 80000 Kg | 10 Kg | 9 x 3 mtr |
| 10000 Kg | 10 Kg | 7.5 x 3 mtr |
| 10000 Kg | 10 Kg | 12 x 3 mtr |
| 150000 Kg | 20 Kg | 7.5 x 3 mtr |
| 150000 Kg | 20 Kg | 16 x 3 mtr |
| 200000 Kg | 20 Kg | 7.5 x 3 mtr |
| 200000 Kg | 20 Kg | 12 x 3 mtr |
Features:
- Mild Steel platform with 150% overload capacity in Traditional & Modular Design, painted with high quality paint to prevent corrosion.
- High Precision Load Cells with IP-67 & IP-68 Protection Classes, which can perform in diverse conditions.
- Rugged Weighbridge terminals with High speed, high resolution A/D & dedicated 8 Bit Microcontroller for signal processing.
- Wide Range of operating voltage (200-240 V AC)
- Wide range of operating temperature(-10 ° C TO 55° C)
- Additional Jumbo Display with 57.5 mm red LED.
- Optional single line message display (3 Feet X 6inches)with weight display in loaded position
- User friendly weighbridge software for weight data management with extensive memory.
- Optional feature for photo capturing of vehicle registration number on weighment slips.
- Optional thermal Printer directly attachable with the weighbridge terminal to print truck number, date, time and weight.
